BASIC LARGE PARTS WASHER & RINSE STATION

$7,800.00

STATION SPECS:

Overall Dimensions: 85”W x 49”D x 75.25”H / Bay: 82”W x 48”D x 48”H (Grate to Spray Bar) / Welded Bare Steel Frame with 18g Galvanized Steel Walls /
Heating & Recirculating Filtration System / Adjustable Overhead Sprayers /
Heavy Duty Angle Grading / Ball Valve Pressure Flow Control /
½” NPT Ball Valve Drain / 30 Gallon Resevoir

Mechanical Air Powered Pump / Polypropylene block and body / Polypropylene Ball Valve Seat / PTFE Diaphragm / Good abrasion resistance, chemical resistance and heat resistance / Max Temperature Limit: 220°F(104.4C) / Air Inlet Size [in]: 3/8 / Max Flow [l/min]: 57 / Max Head [m]: 84

HEATING SYSTEM:

Heater: Screw Plug Heating Element / High Temperature Fitting / EPDM Gasket / 1000W, 110V / Adjustable Dial Thermostat / 3 Blade Power Cord

ON SITE INSTALLATION CONSULTATION AND TRAINING AVAILABLE FOR ALL EQUIPMENT. PRICING BASED ON EQUIPMENT AND LOCATION.

Contact us at (915)313-9333 ext 15 for Shipping Quotes and Lead Times

SKU: BLPW110519 Category:

Description

STATION SPECS:

Overall Dimensions: 85”W x 49”D x 75.25”H / Bay: 82”W x 48”D x 48”H (Grate to Spray Bar) / Welded Bare Steel Frame with 18g Galvanized Steel Walls /
Heating & Recirculating Filtration System / Adjustable Overhead Sprayers /
Heavy Duty Angle Grading / Ball Valve Pressure Flow Control /
½” NPT Ball Valve Drain / 30 Gallon Resevoir

Mechanical Air Powered Pump / Polypropylene block and body / Polypropylene Ball Valve Seat / PTFE Diaphragm / Good abrasion resistance, chemical resistance and heat resistance / Max Temperature Limit: 220°F(104.4C) / Air Inlet Size [in]: 3/8 / Max Flow [l/min]: 57 / Max Head [m]: 84

HEATING SYSTEM:

Heater: Screw Plug Heating Element / High Temperature Fitting / EPDM Gasket / 1000W, 110V / Adjustable Dial Thermostat / 3 Blade Power Cord

ON SITE INSTALLATION CONSULTATION AND TRAINING AVAILABLE FOR ALL EQUIPMENT. PRICING BASED ON EQUIPMENT AND LOCATION.

Contact us at (915)313-9333 ext 15 for Shipping Quotes and Lead Times
