Straight Sheet Metal Brake HB-12014

$7,695.00

DESCRIPTION

With a welded steel frame, this manual sheet metal bender is strong enough to bend 14 gauge mild steel across its full length of 10 feet (120”). The HB-12014 will last for years in any shop.



  • This industrial sheet metal bender has a maximum bend angle of 135°.
  • 10 foot sheet metal brake made using only the highest-quality materials.
  • Machined bending leaf pivots ride in precision bushings, allowing for better bend tolerances and minimizing operator fatigue.
  • 2 massive counterweights on the bending apron reduce the effort of bending at maximum capacity.
  • 1-piece bending blade, machined to perfection, achieves tight bend radiuses.
  • Top beam depth adjusts to fit different material thickness.
  • Comes standard with stop rod to ensure repeatability for production runs.
  • Thick, fully-welded steel plate frame maintains accuracy and keeps the machine from buckling at full capacity.
  • Baileigh Industrial covers this 10 foot sheet metal brake with a 1-year parts warranty.

SPECIFICATIONS

Item Number HB-12014
Country of Manufacture Taiwan
Min Reverse Bend .625″
Thickness (SS) 14 ga. (18 ga.)
Capacity 144″
Beam Adjustment 1″
Bend Angle 0 – 135°
Power Manual
Shipping Weight 3400lbs
Length 120”
Shipping Dimensions (Inches) 145x33x42

* specifications subject to change without notice.
